pH Probes

pH Probe BM SZ-HJ-PH

This is an online pH electrode, adopts electrode measuring method, and realizes the automatic temperature compensation in the interior of the electrodes, Automatic identification of standard solution.

  • Digital pH Probe
  • Bm sz-hj-ph
  • 1W
  • Power supply: 12vDC
pH Probe BM SZ-HJ-PH

Overview

This is an online pH electrode, adopts electrode measuring method, and realizes the automatic temperature compensation in the interior of the electrodes, Automatic identification of standard solution. Electrode adopt imported composite electrode, high precision, good stability, long lifetime, with rapid response, low maintenance cost, real-time online measurement characters etc. The electrode using standard Modbus RTU (485) communication protocol, 24V DC power supply, four wire mode can very convenient access to sensor

Features

  • The characteristics of industrial sewage electrode, can work stably for a long time
  • Built in temperature sensor, real-time temperature compensation
  • RS485 signal output, strong anti-interference ability, the output range of up to 500m
  • Using the standard Modbus RTU (485) communication protocol
  • The operation is simple, the electrode parameters can be achieved by remote settings, remote calibration of electrode
  • 24V DC power supply.

Specification

ModelBM SZ-HJ-PH
Parameter measurementpH, Temperature
Measure rangepH :0.0-14.0
Temperature : (0-50.0)°C
AccuracypH :±0.1pH
Temperature :±0.5°C
ResolutionpH :0.01pH
Temperature :0.1°C
Power supply24V DC
Power dissipation1W
Communication modeRS485(Modbus RTU)
Cable lengthCan be ODM depend on user’s requirements
Housing materialABS
InstallationSinking type, pipeline, circulation type etc.
Overall size230mm×φ 30mm

Connection Diagram

End-on view of a pH probe showing the sensing tip

Images & Videos

pH sensor lying on a white surface with its sensing end facing the camera

Get the BM SZ-HJ-PH datasheet

Ask about the BM SZ-HJ-PH

Tell us about your ponds or tanks and we will confirm compatibility, availability and pricing.
